Introduction of burst disc for storage tank:
Burst disc for storage tank is a non-reclosing pressure relief device composed of a bursting disc assembly and a clamp. Under the set bursting pressure difference, when the pressure difference on both sides of the burst disc for storage tank reaches the set value, the bursting disc will rupture immediately and release the fluid medium.
Advantages of burst disc for storage tank:
1. Our burst disc for storage tank has fast pressure relief speed and large pressure relief volume. The relief area of the burst disc can be determined in advance according to the process requirements. It is particularly suitable for reactors where pressure is generated or increased by chemical reactions of materials.
2. The no-leak rupture disc can ensure absolute no leakage, and is particularly suitable for pressure vessels whose working medium is flammable and explosive substances or highly toxic gases.
3. The no-leak rupture disc device is suitable for various pressure vessels, including gas and liquid media, and is not affected by the state of the medium (such as high-viscosity liquids, easily crystallized liquids or powdery substances).
Correct installation location of rupture disk for cryogenic equipment:
The installation location of rupture disk for cryogenic equipment should be carefully considered. Generally speaking, it needs to be installed below or to the side of the tank, which can effectively reduce the chance of explosion.
If rupture disk for cryogenic equipment is installed on the top of the tank, it will cause great damage to the tank itself. In addition, the number of bursting discs should be determined according to the size and volume of the tank to ensure safety.
In actual application, the installation location of Rupture disk for cryogenic equipment should be comprehensively considered based on multiple factors such as the structure of the tank, internal pressure, and stored materials. The installation location of the bursting disc should be reasonably planned in the early design stage.
FAQ:
1. What media is burst disc for no leakage suitable for?
Burst disc for no leakage is suitable for various gases, liquids and corrosive media, especially for applications in anaerobic storage tanks.
2. What should be paid attention to when installing burst disc for no leakage?
When installing burst disc for no leakage, ensure that the flange or threaded connection is tight to prevent leakage; at the same time, the installation and commissioning should be carried out according to the specified bursting pressure to ensure that the Burst disc for no leakage opens accurately at the set pressure.
3. What is the service life of no-leak rupture disc?
The service life of no-leak rupture disc depends on the use environment and working conditions. Generally, it can be used for many years under normal use conditions, but it is recommended to check and replace it regularly.
Our company specializes in the production of various types of no-leak rupture discs and has been focusing on the explosion-proof field for sixty years. If you are interested in our no-leak rupture disc products, please leave a message!
