Introduction of pressure relief devices:
Pressure relief devices for gas cylinders are regarded as an important safety measure for high-pressure gas storage and distribution systems. Pressure relief devices for gas cylinders are installed on the gas valves of high-pressure gas cylinders to minimize the risk of gas cylinder rupture and prevent the rupture of normally pressurized gas cylinders when accidentally exposed to fire or high temperature. The design types of pressure relief devices for gas cylinders include fusible plugs, bursting discs, bursting discs with fusible metal backing, and spring-loaded pressure relief valves.
Maintenance of high pressure gas cylinder pressure relief device:
High pressure gas cylinder pressure relief devices can only function and maintain good long-term performance if they are properly maintained. Care should be taken when handling and storing compressed gas cylinders to avoid blocking the pressure relief device channels and components in any way that may affect the function of the device. All high pressure gas cylinder pressure relief devices must be internally inspected to confirm whether there is corrosion, damage, rust, blockage of the pressure relief device channels, or mechanical defects such as leakage or fusible metal extrusion. If there is any doubt about the suitability of the high pressure gas cylinder pressure relief device, the cylinder should not be inflated until the device is confirmed to be suitable. In addition, unauthorized personnel should not attempt to repair the pressure relief device. If the pressure relief valves for technical gases need to be repaired or refurbished, the manufacturer can perform the repair, but it must be retested to ensure that it meets the requirements.
Advantages of high pressure gas cylinder pressure relief device:
1.The soft seat seal of pressure relief valves for technical gases provides lower operating torque.
2.The valve seat of pressure relief valves for technical gases is stuck to avoid squeezing and valve clogging.
3.The pressure relief valves for technical gases achieve high sealing integrity through diaphragm seal.
4.High performance thrust pad of pressure relief valves for technical gases.
About us:
We are the first professional manufacturer in China to focus on the design, production, sales and service of bursting disc safety devices. We have been recognized as a high-tech enterprise by the Provincial Department of Science and Technology. The company has participated in the drafting and formulation of many national and industry standards such as "Burst Discs and Burst Disc Safety Devices" and "Safety Technical Supervision Regulations for Burst Disc Devices". The various types of bursting disc devices it produces are widely used in petrochemical, pharmaceutical, metallurgical, power generation, environmental protection, storage and transportation and other industries.
